Double Head Weigh Filler Machine
The Double Head Weigh Filler Machine (Model AI-1006) is a high-precision, automatic pouch packing solution engineered for the accurate filling of freely flowing granular, coarse, and powdered products. With a weighing range of 10g to 500g, this machine is designed to meet the needs of industries demanding consistency, speed, and hygiene in packaging.
The machine is ideal for packaging pulses, rice, wheat, sugar, grains, cereals, seeds, dry fruits, cashews, almonds, pistachios, whole spices, namkeen, snacks, biscuits, chocolates, candies, cookies, protein bites, tea leaves, herbal products, herbal granules, bath salts, beads, capsules, tablets (non-powder), fertilizers, detergent granules, plastic granules, and hardware items such as screws and bolts. Its robust performance and adaptability make it one of the most reliable pouches packing machines for modern production environments.
Product Range
Key Features
- 24x7 operation with virtually maintenance-free design
- User-friendly HMI with real-time parameter monitoring
- Dual vibratory feeder system for enhanced filling accuracy
- Self-learning software to minimize manual settings
- Eye mark controller for precise sealing and cutting
- Batch printing provision for production traceability
- Former type forming system for uniform pouch appearance
- Leak-proof sealing with advanced vertical sealing method
- Options for strip cut / single cut
- Provision for nitrogen flushing to extend shelf life
Nitrogen gas flushing unit (for extended shelf life)
Hole punching unit
TTO for batch/date printing
Gusseting unit
Fast-change film roll unit
D-Cut option
Technical Specifications
| Model | AI-1006 |
| Forming Type | Former |
| Grammage | 10–500g |
| Accuracy | 0.1 – 0.5 |
| Roll Width (mm) | 170–370 mm |
| Pouch Width | 75–175 mm |
| Pouch Length (mm) | 75–225 mm |
| Vertical Seal Width (mm) | 10/15 typical |
| Horizontal Seal Width (mm) | 10/15 typical |
| Speed (PPM) | 8–12 DPM* |
| Output | 36–400 kg/hr.* |
| Hopper | 1 no |
| Pan | 2 nos |
| Vibratory Feeder | 2 nos |
| Delivery Chute | 1 no |
| Floor Area | 23 sq.ft |
| Power Supply | 1 Phase, 230 VAC |
| Air Supply | 2 HP, 8 Bar Pressure, 2 CFM |
| Serration & Cutting | Count cutting provided, count to be fed through HMI |
| Control of FFS | Through microcontroller |
| Eye Mark Controller | Optional |
| Process Parameter Setting | Through HMI |
| Roller Mechanism | Through Steeper/Servo motor |
| Film Draw Mechanism | Die roller |
| Horizontal Sealing Mechanism | Pneumatic |
| Vertical Seal Mechanism | Through die roller |
| Material of Construction | All contact parts SS304, other parts MS |
