14 Head Weigh Filler Machine
The 14 Head Multihead Weigher Packing Machine is a high-performance solution engineered for large-scale, high-speed, and high-accuracy packaging operations. Operating at an impressive 55– 85 packs per minute, this machine is designed for industries where precision and efficiency are critical. Its combination weighing technology ensures consistency, while the indigenously developed microcontroller-based system guarantees reliability and smooth operations.
This advanced Made in India Multihead Weigher Machine is suitable for a wide variety of applications including snacks such as chips, namkeen, wafers, farsan, fryums, makhana, and popcorn; grocery products like pulses, dals, sugar, peanuts, grains, poha, and puffed rice; dry consumables including nuts, dry fruits, whole spices, tea, and coffee beans; frozen food items like peas, carrots, okra, nuggets, fries, prawns, and shrimps; confectionery such as chocolates, candies, toffees, and lollipops; as well as pet food and small hardware items such as screws, washers, and dowel pins.
Product Range
Optional Accessories
- Nitrogen gas flushing unit
- Hole punching unit
- TTO for batch/date printing
- Gusseting unit
- Fast-change film roll unit
- D-Cut option
Key Features
- Made in India – designed, developed, and manufactured in-house
- Large HMI touch screen with indigenous software
- Motorized pulling system for smooth film handling
- Microcontroller-based system for precision control
- Strip or individual count cutting option
- Single phase operation for energy efficiency
- All electronic control instruments manufactured in-house
Nitrogen gas flushing unit (for extended shelf life)
Hole punching unit
TTO for batch/date printing
Gusseting unit
Fast-change film roll unit
D-Cut option
Technical Specifications
| Materials | Granular, Fluffy, Irregular shaped, Solids |
| Max Capacity | 100g – 1kg |
| Accuracy | 0.1 – 0.5 gms |
| Max Speed | 55–85 pouches per minute* |
| Pouch Width | 50–250 mm |
| Pouch Length | 65–330 mm |
| Film Width | 120–530 mm |
| Power Requirement | 2KW, Single Phase 230 VAC |
| Air Requirement | 2HP, 8 Bar Pressure, 2 CFM |
| Forming Type | Collar |
| Vertical Seal Width | 10/15 mm typical |
| Horizontal Seal Width | 10/15 mm typical |
| No. of Weighing Pans | 14 Nos. |
| Dimensions (W x H x D) | 8 x 12 x 7 ft. |
| Serration & Cutting | Count cutting provided, count to be fed through HMI |
| Eye Mark Controller | Provided |
| Process Parameter Setting | Through HMI |
| Film Draw Mechanism | Steeper/Servo motor |
| Horizontal Sealing Mechanism | Pneumatic |
| Vertical Seal Mechanism | Pneumatic |
| Material of Construction | All contact parts SS304 |
