Description
| SoC | DM&P SoC CPU Vortex86DX- 800MHz Real-Time Clock with Lithium Battery Backup |
| Cache | L1:16K I-Cache, 16K D-cache L2 Cache 128KB |
| BIOS | AMI BIOS |
| System Memory | 256/512MB DDR2 Onboard |
| Watchdog Timer | Software programmable from 30.5μ sec. to 512 sec. x 2 sets (Watchdog 1 fully compatible with M6117D) |
| VGA | XGI Volari Z9s Chipset VGA and TFT Flat Panel Interface Support Onboard 32MB VGA Memory, support resolution up to 1280×1024,16M colors |
| LAN | Integrated 10/100Mbps Ethernet |
| Audio | CM119 USB Audio controller |
| Flash Disk Support | Onboard 4MB SPI Flash Disk MSTI EmbedDisk Module (16MB and above) 44-pin IDE to Micro SD (Optional) |
| PWM | 24~32 Channels |
| I/O Interface | Enhanced IDE port (UltraDMA-100/66/33) x1 RS-232 port x3 RS-232/422/485 port x1 USB port (Ver2.0) x4 16-bit GPIO port x2 10/100Mbps Ethernet port x1 |
| Connectors | 2.0mm 44-pin box header for IDE x1 2.0mm 20-pin box header for 16-bit GPIO x2 2.0mm 10-pin box header for RS-232 x4 2.0mm 10-pin box header for USB x2 2.0mm 10-pin box header for VGA x1 2.0mm 44-pin box header for LCD x1 2.54mm 5-pin box header for Keyboard x1 2.54mm 5-pin header for Mouse x1 2.54mm 3-pin header for RS-485 x1 1.25mm 4-pin wafer for Line-out/MIC-in x2 1.25mm 6-pin wafer for JTAG x1 External RJ-45 connector for Ethernet x1 |
| Power Requirement | Single Voltage +5V @ 740mA |
| Weight | 63g |
| Board Size | 100 x 66mm (3.94 x 2.6 inches) |
| Operating Temperature | -20°C ~ +70°C -40°C ~ +85°C (Optional) |
Order Information:
| Part Number | Description |
| VDX-6318RD | Vortex86DX Tiny CPU Module with 256MB DDR2 |
| VDX-6318RD-512 | Vortex86DX Tiny CPU Module with 512MB DDR2 |
Additional Information:
The VDX-6318RD family of low-power x86 embedded controller is designed to meet Tiny specification and integrated with the following features.
The VDX-6318RD Tiny family of embedded controllers is designed with backward compatibility in mind to provide a migration path for projects facing end-of-life challenges with their existing x86 based Tiny controller. The VDX-6318RD family of controllers is designed as a plug in replacement with backward compatibility to support legacy software to help extend the current product life cycle without heavy re-engineering.
VDX-6318RD is suitable for a broad range of data-acquisition, Industrial automation, Process control, Automotive controller, AVL, Intelligent Vehicle management device, Medical device, Human-machine interface, Robotics, machinery control And more…application that required small footprint, low-power and low-cost hardware with an open industry standard such as Tiny.
